HXA1202V X-axis MEMS Accelerometer Sensor

HXA1202V is a high-performance X-axis MEMS accelerometer. Supports ± 50g full-scale output performance. The output acceleration data is in 24 bit binary complement format and can be accessed through SPI digital compatible interface. HXA1202V can achieve accurate acceleration measurement under complex working conditions, suitable for applications such as attitude measurement and vibration monitoring.

SKU HXA1202V Category MEMS Accelerometer Tags Accelerometer, MEMS

Description

MEMS Accelerometer

Specifications

Sensitive axis	X-axis (parallel to device packaging)
Range	± 50g
Bandwidth (3dB)	100Hz
Zero bias instability	50 ug (10 smooth, 1σ)
Scale factor nonlinearity	1000ppm
Typical working current	10mA
Digital output interface	Compatible with SPI
Temperature sensor	Integrated temperature sensor
Working voltage range	4.75~5.25 V
Working temperature range	-40°C ~ +125°C
LCC package -48 pins	7.8 x 5.8 x 3 mm
Impact resistance (charged)	10000g
