HXA315 Industrial Grade 3-Axis MEMS Accelerometer

HXA315 is an industrial grade 3-axis MEMS accelerometer that supports user configured ranges (± 2g, ± 8g). The output acceleration data is in 20 bit binary complement format and can be accessed through SPI digital compatible interface. HXA315 can achieve accurate acceleration measurement under complex working conditions, suitable for industrial applications such as inclination measurement, deformation monitoring, vibration monitoring, etc.

SKU HXA315 Category MEMS Accelerometer Tags Accelerometer, MEMS

Description

3-Axis MEMS Accelerometer

Specifications

Sensitive axis	3-axis (X/Y/Z)
Range	±2g，±8g
Bandwidth (3dB)	1000Hz
Zero bias stability	10ug（Allan）
Typical working current	0.6mA
Digital output interface	Compatible with SPI
Temperature sensor	Integrated temperature sensor
Working voltage range	3.0~3.6V
Working temperature range	-40°C ~ +85°C
LCC package -48 pins	6 x 6 x 2.25 mm
Impact resistance (charged)	5000g
